DLF1.1

The Bosch Rexroth Indramat DLF1.1 module is a high-precision positioning interface card from the VT-UK2 Universal Cards series designed for demanding industrial automation applications. This Positioning Interface Module features a 2048-fold signal period resolution and a robust 15-pin D-SUB connector to ensure reliable communication with external incremental encoders. Operating as an integral component within drive controllers, the DLF1.1 facilitates accurate position control by processing sine-wave signals and converting them into high-resolution internal feedback.

In technical terms, the DLF1.1 supports sine wave signal inputs at frequencies up to 150 kHz, enabling rapid response and dynamic control in high-speed applications. The module accepts external position data through an external incremental encoder interface and is powered by a standard 24 V DC supply voltage. Its plug-in extension module capability allows users to expand functionality by integrating additional signal processing boards without complex rewiring. The high-resolution internal control ensures consistent position feedback, essential for precision tasks in automated systems.

Beyond its core specifications, the DLF1.1 excels in compatibility and flexibility. Its compact design and industry-standard connector type support straightforward retrofitting into existing control cabinets. The use of sine-wave signal input reduces noise susceptibility and enhances measurement accuracy under varying environmental conditions. The plug-in extension module design further simplifies maintenance and scalability, allowing for future upgrades. By offering precise position control, fast signal processing, and seamless integration, the DLF1.1 Positioning Interface Module delivers increased efficiency, reliability, and productivity in industrial automation environments.
