The Bosch Rexroth Indramat CSH01.1C-ET-ENS-EN1-NNN-S2-S-NN-FW from the CSH Advanced Controllers series is a compact single-axis advanced control unit equipped with a MultiEthernet master communication interface and supporting Indradyn/Hiperface/1 Vpp/TTL primary encoder options. It features two analog outputs, one analog input, an inrush current of ~4 A and power consumption of ~7.5 W, delivering up to 95% efficiency. The unit operates with switching frequencies from 2 to 16 kHz, a minimum SERCOS cycle time of 250 µs, and current control cycles between 62.5 and 125 µs, ensuring high dynamics and precise motion control.
Analog Outputs
2
Master Communication
MultiEthernet
Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
