The Bosch Rexroth Indramat CSH01.1C-NN-EN1-EN2-MD2-NN-S-NN-FW from the CSH Advanced Controllers series delivers precise motion control with high flexibility and reliability. This CSH01.1C-NN-EN1-EN2-MD2-NN-S-NN-FW unit supports a Primary Encoder Option HSF/RSF to guarantee accurate position feedback. It features 2 Analog Outputs for seamless integration with analog feedback loops, and is designed with a Master Communication: Not Equipped architecture for customized communication networks. The controller’s modular design and standard DIN-rail mounting simplify installation and expansion in existing control cabinets.
Engineered for industrial automation, the controller supports advanced motion profiles, including linear and S-curve ramping, with precise synchronization across multiple axes. Its encoder interface leverages the HSF/RSF option for high-speed feedback at microsecond resolution, ensuring minimal jitter in demanding applications. The dual analog outputs enable direct adjustment of external actuators and valves without additional signal converters. The controller’s firmware (denoted by the FW suffix) provides built-in diagnostic capabilities, including real-time monitoring of encoder status and output channel health.
Compact yet robust, the CSH01.1C-NN-EN1-EN2-MD2-NN-S-NN-FW achieves reliable operation across a wide temperature range and supports hot-swapping for minimal downtime. Bosch Rexroth Indramat’s strict quality controls and in-field service network ensure long-term performance and rapid support. This advanced control system is ideal for packaging machinery, gantry systems, and high-speed pick-and-place applications where precision and flexibility are paramount.
Analog Outputs
2
Master Communication
Not Equipped
Primary Encoder Option
HSF/RSF
