The Bosch Rexroth Indramat CSH01.1C-NN-EN1-NNN-MEM-L2-S-NN-FW from the CSH Advanced Controllers series combines modular adaptability and robust functionality in a single footprint. This advanced control system features Analog Outputs: 2 for precise signal transmission and a Primary Encoder Option: HSF/RSF to support high-resolution feedback. The unit’s Master Communication: Not Equipped design simplifies integration where dedicated networking is not required and reduces configuration complexity. Engineered to accommodate a space-saving design, the controller also includes a starting lockout feature that prevents unintended startups during maintenance or repair.
Integration and user interaction are optimized through a dedicated Operator’s Panel H1 for rapid setup and diagnostics, while an optional encoder emulation module at X10 enhances flexibility in motion profiling. The control section supports both forced and free ventilation cooling methods to maintain stable operation under varying load conditions. Installation is streamlined with compatibility at altitudes up to 1000 m, and the enclosure is designed to fit standard panels without additional mounting hardware. This combination of features makes the CSH01.1C ideal for demanding applications in packaging, material handling, and robotic automation.
Reliability is further ensured by an operating temperature range up to +40 °C and compliance with environmental parameters for moisture and pollution. A one-year replacement warranty underscores Bosch Rexroth Indramat’s commitment to quality and customer satisfaction. With its comprehensive feature set and proven performance, the CSH01.1C-NN-EN1-NNN-MEM-L2-S-NN-FW controller offers a future-proof solution for sophisticated motion control architectures.
Analog Outputs
2
Master Communication
Not Equipped
Primary Encoder Option
HSF/RSF
