CSH01.1C-NN-ENS-EN2-EN2-NN-S-NN-FW

The Bosch Rexroth Indramat CSH01.1C-NN-ENS-EN2-EN2-NN-S-NN-FW from the CSH Advanced Controllers series is a sophisticated, configurable single-axis control section that integrates seamlessly into high-performance drive systems. This module features a Primary Encoder Option: Indradyn/Hiperface/1 Vpp/TTL interface for high-resolution position feedback and offers Analog Outputs: 2 channels for precise process control. It is Master Communication: Not Equipped, making it ideal for modular designs where communication is handled by dedicated modules. Engineered with industry-leading electronics, it provides robust performance and flexible integration for advanced motion control applications.

This control section supports advanced encoder evaluation, including dual channels for 5 V encoders, and accepts supply voltages of 12 V for primary feedback devices. Commissioning and diagnostics are performed using the Rexroth IndraWorks software, enabling remote parameter configuration, firmware updates, and real-time monitoring of operational data. The built-in control panel also allows for setting drive addresses, configuring default load parameters, establishing position references, and adjusting analog output scaling directly on the unit. All configuration tasks can be recorded for traceability and streamlined maintenance protocols.

Designed for industrial environments, the CSH01.1C-NN-ENS-EN2-EN2-NN-S-NN-FW belongs to Category C3 according to IEC 61800-3, ensuring immunity to electromagnetic disturbances in harsh factory settings. For installations on public mains supplying residential areas, appropriate radio interference filters must be fitted to maintain compliance. This device exemplifies Bosch Rexroth Indramat’s commitment to precision, reliability, and ease of integration in complex automation systems.
