CSH01.1C-NN-ENS-EN2-MA1-S1-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers. The CSH01.1C-NN-ENS-EN2-MA1-S1-S-NN-FW is a high-performance module from the CSH Advanced Controllers family by Bosch Rexroth Indramat. This advanced control section features Master Communication: Not Equipped, ensuring simplified network topologies when remote bus masters are unnecessary. Its Primary Encoder Option: Indradyn/Hiperface/1 Vpp/TTL interface supports a wide range of high-resolution encoders, while the dual Analog Outputs: 2 channels deliver precise feedback signals for downstream automation devices. Designed for modularity, the control unit plugs directly into compatible power sections of the Rexroth IndraDrive ecosystem, streamlining cabinet layout and reducing wiring complexity.

Equipped with an internal DC power supply, the single-axis control board operates autonomously, eliminating the need for external aux supplies. Two dedicated Encoder Interfaces allow simultaneous connection of IndraDyn S or MSK motor sensors with either 12 V or 5 V excitation. The integrated Safety Technology I/O Module provides safety-related standstill, drive interlock, and reduced-speed functions conforming to ISO standards. An optional Analog I/O Extension boosts resolution in analog signal processing for applications demanding sub-percent accuracy. Engineers benefit from the front-mounted Single Line Display, which reports operating states, command feedback, and diagnostic codes in real time. All field connections use spring-loaded and screw-type terminal blocks, accommodating ferrules or bare conductors without adapters. The controller's industrial EMC rating ensures electromagnetic compatibility in high-noise factory environments.

Seamless integration into the Bosch Rexroth IndraDrive infrastructure guarantees coherent motion coordination and unified parameter management across multi-axis systems. The robust design and certified safety module deliver reliable performance in handling, packaging, and machine-tool applications. With its configurable I/O, encoder flexibility, and industrial-grade EMC immunity, the CSH01.1C-NN-ENS-EN2-MA1-S1-S-NN-FW offers a turnkey solution for demanding automation tasks where uptime and precision are critical.
