The CSH01.1C-PB-EN2-EN2-MA1-NN-S-NN-FW from Bosch Rexroth Indramat features PROFIBUS master communication and 2 analog outputs. Part of the CSH Advanced Controllers series, it supports EnDat 2.1/1 Vpp/TTL encoding and draws 7.5 W. It measures 241×103×49.5 mm and mounts vertically with natural convection cooling.
Operating temperatures range from 0 to 40 °C with a maximum elevation of 1000 m. An integrated RS-232 port and removable memory card slot enhance connectivity. Control cycles are configurable up to 500 μs and switching frequencies up to 16 kHz.
Analog Outputs
2
Master Communication
PROFIBUS
Primary Encoder Option
EnDat 2.1/1 Vpp/TTL
