CSH01.1C-PB-EN2-NNN-MA1-L1-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CSH01.1C-PB-EN2-NNN-MA1-L1-S-NN-FW is part of the advanced CSH Advanced Controllers series, engineered for precise servo motion control and automation. This industrial controller leverages a PROFIBUS master communication interface and supports a primary encoder option of EnDat 2.1/1 Vpp/TTL, enabling high-resolution feedback and real-time data exchange. With 2 analog outputs, the unit provides versatile signal routing for downstream drives or monitoring equipment. Designed to manage position, speed, and torque in servo systems, it is ideally suited for applications demanding stringent motion accuracy and seamless network integration.



This control system offers a robust PROFIBUS communication protocol for synchronized multi-axis coordination, reducing cycle times and simplifying topology. The EnDat 2.1/1 Vpp/TTL encoder interface ensures precise feedback with minimal latency, supporting advanced closed-loop control strategies. Two high-precision analog outputs allow for smooth voltage or current signals to auxiliary devices or diagnostic modules. All interfaces are implemented with industrial-grade connectors to maintain signal integrity under electrical noise and harsh conditions.



Compatible with any servo drive or actuator supporting PROFIBUS and EnDat standards, the CSH01.1C-PB-EN2-NNN-MA1-L1-S-NN-FW delivers reliable performance in diverse manufacturing environments. Its digital communication and analog output architecture enable efficient integration into metal forming, robotics, packaging, and assembly lines. By centralizing communication and feedback in a single controller, it reduces wiring complexity and improves system diagnostics. The result is enhanced machine uptime, lower commissioning effort, and maximum throughput for demanding industrial applications.

Technical Specifications

Analog Outputs
2

Master Communication
PROFIBUS

Primary Encoder Option
EnDat 2.1/1 Vpp/TTL
