CSH01.1C-PB-ENS-EN1-EN2-S2-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CSH01.1C-PB-ENS-EN1-EN2-S2-S-NN-FW controller from the CSH Advanced Controllers series integrates a Master Communication: PROFIBUS interface with a versatile Primary Encoder Option: Indradyn/Hiperface/1 Vpp/TTL solution and offers Analog Outputs: 2 for flexible motion feedback. This advanced control section mounts directly onto the power section to draw its operating power and delivers comprehensive processing functions for IndraDrive systems. A rugged front panel houses all I/O connectors and module slots for seamless field expansion. The unit is engineered for professional automation environments, combining modularity and high-speed data exchange in one compact package.



All electrical and functional parameters are designer-friendly: the main control section consumes 7.5 Watts while each optional encoder module—whether HSF/RSF, EnDat 2.1, or IndraDyn—draws just 6 Watts of power. A pre-installed safety module supports safe motion functionality, and multiple front-panel slots accept additional I/O or safety modules without tools. There is also a dedicated slot for a removable memory card plus an integrated RS-232 interface and combined digital and analog I/O channels for ultimate connectivity.



Firmware for the CSH01.1C-PB-ENS-EN1-EN2-S2-S-NN-FW is ordered separately, streamlining upgrades and backward compatibility. Installation and handling must be performed by trained and qualified personnel to ensure compliance with industrial safety standards and to maximize system reliability.

Technical Specifications

Analog Outputs
2

Master Communication
PROFIBUS

Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
