The Bosch Rexroth Indramat CSH01.1C-PB-ENS-EN2-MD2-S1-S-NN-FW controller belongs to the CSH Advanced Controllers series and serves as a high‐performance drive control section. It is engineered for use within drive systems and features a PROFIBUS master communication module for seamless network integration. The unit supports a Primary Encoder Option of Indradyn/Hiperface/1 Vpp/TTL and provides 2 Analog Outputs, enabling precise feedback and signal conditioning for demanding industrial applications. This advanced control section manages one drive axis and implements built-in safety technology mechanisms for secure operation.
Incorporating robust technical specifications, the CSH01.1C-PB-ENS-EN2-MD2-S1-S-NN-FW is classified as a Category C3 component under IEC 61800-3, ensuring resistance to electromagnetic interference in harsh environments. It offers a single configuration slot for flexible parameterization and features a dedicated memory card slot supporting two types of multimedia cards for firmware updates and data logging. The control section is housed within the power section of the drive controller and connects via a simple plugin action, simplifying installation and maintenance. Digital inputs and outputs at terminals X31.8 and X31.9 require an external supply voltage, and the device incorporates a PROFIBUS optional module for master communication.
Designed for industrial use only, this CSH controller measures 241 × 103 × 49.5 mm and can become hot during operation or immediately after shutdown, necessitating a power disconnection before maintenance. The unit carries a one-year warranty and must be commissioned in compliance with national regulations and application safety standards. Its durable construction and category rating deliver reliable performance in machine tools and automated systems. By leveraging precise encoder feedback, flexible communication, and modular configuration, the CSH01.1C-PB-ENS-EN2-MD2-S1-S-NN-FW enhances system efficiency, reduces downtime, and supports long-term operational stability in industrial drive applications.
Analog Outputs
2
Master Communication
PROFIBUS
Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
