CSH01.1C-PB-ENS-EN2-MEM-L1-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CSH01.1C-PB-ENS-EN2-MEM-L1-S-NN-FW from the CSH Advanced Controllers series is a high-performance control section offering 2 Analog Outputs and supporting a Master Communication PROFIBUS interface. This module features a Primary Encoder Option Indradyn/Hiperface/1 Vpp/TTL for precise motion feedback and an optional ENS encoder evaluation module for advanced diagnostics. With a rugged design that includes a separate type plate bearing the unique type designation, this unit is fully configurable to meet application-specific requirements. Installation must observe ambient limits and proper grounding to ensure reliable operation.



Engineered for demanding industrial environments, the CSH01.1C-PB-ENS-EN2-MEM-L1-S-NN-FW provides seven to eleven digital inputs alongside high-side switches for digital outputs, enabling versatile I/O configurations. The PROFIBUS port meets EIA-RS485 standards for robust, noise-immune communication across extended cable runs. A maximum pulse width of 100 ms accommodates high-speed signaling tasks, while built-in probe inputs facilitate precise detection of specialized markers such as glue dots. The housing can reach temperatures above 60 °C under heavy load, so external protective enclosures are recommended to safeguard personnel and equipment.



Maintenance and commissioning are streamlined thanks to standard compliance and a comprehensive one-year warranty. All covers and guards must be installed before energizing to prevent exposure to hazardous voltages, and disconnecting from mains power is mandatory before access. Handling and mounting require suitable lifting equipment to avoid mechanical damage. When integrated into machine-level control architectures, this advanced CSH controller delivers precise motion coordination, secure data exchange, and scalable I/O expansion for modern automation systems.

Technical Specifications

Analog Outputs
2

Master Communication
PROFIBUS

Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-PB-ENS-EN2-MEM-L1-S-NN-FW.
