The Bosch Rexroth Indramat CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW advanced controller from the CSH Advanced Controllers series is a single-axis control section designed for PROFIBUS master communication (PROFIBUS). It integrates an EN2 module supporting a Indradyn/Hiperface/1 Vpp/TTL encoder primary encoder option and provides 2 analog outputs for flexible signal interfacing. Dual conductors per terminal using TWIN ferrules simplify wiring, and the unit is free of harmful substances. Power is supplied via 0 V/24 V connectors, while firmware and parameters can be loaded from a memory card. Five selectable switching frequencies (2 kHz–16 kHz) optimize performance. The EN2 module typically operates at 11.6 V with up to 500 mA output, and the controller carries a one-year warranty. Proper installation per manufacturer safety regulations ensures reliable operation.
Analog Outputs
2
Master Communication
PROFIBUS
Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
