CSH01.1C-PB-ENS-ENS-NNN-L2-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CSH01.1C-PB-ENS-ENS-NNN-L2-S-NN-FW from the CSH Advanced Controllers series integrates high-performance motion control with flexible I/O and communication capabilities. This advanced control system features 2 analog outputs, a native PROFIBUS master communication interface, and a selectable Indradyn/Hiperface/1 Vpp/TTL primary encoder option for precise feedback. Factory-fitted modules include a safety module supporting Safe Torque Off and two dedicated encoder modules, with an additional hardware module slot available for future upgrades. Connectivity is enhanced by a front-mounted RS-232 serial interface and one memory card slot for parameter backup and data logging, while power consumption is optimized at 7.5 W for the basic unit, 6 W per encoder module, 2 W for the Profibus module, and 1 W for the control panel.



Configuration and diagnostics are performed via the intuitive front-panel display and keypad, offering real-time status monitoring and parameter adjustment without external tools. All integrated I/O and communication interfaces are located on the accessible front panel alongside existing module slots and the memory card slot, simplifying cabinet layout and maintenance. Engineered for vertical installation, the controller relies on natural convection cooling to eliminate moving parts and ensure silent operation under load. Recommended for ambient temperatures between 0 and 40 °C, the design prevents overheating and supports reliable performance in varied industrial environments.



Rapid commissioning and firmware updates are achieved through the standard control panel interface and plug-in firmware modules, reducing machine downtime and simplifying version management. Its modular hardware design, combined with robust PROFIBUS, encoder and safety module support, delivers a future-proof platform adaptable to evolving application requirements. The CSH01.1C-PB-ENS-ENS-NNN-L2-S-NN-FW is an ideal choice for demanding motion control installations that require high flexibility and precise operational safety.

Technical Specifications

Analog Outputs
2

Master Communication
PROFIBUS

Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
