CSH01.1C-S3-ENS-ENS-NNN-L1-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

CSH01.1C-S3-ENS-ENS-NNN-L1-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers is a high-performance single-axis control unit designed for demanding industrial automation environments. This advanced control system features an intuitive integrated operator panel with a one-line display and keypad for straightforward command entry and monitoring. It ships fully configured with a type label detailing part number, serial number, bar code, hardware index, and production batch, ensuring rapid identification and traceability upon installation. Built on a modular hardware platform, it supports flexible configuration to match a wide range of machine dynamics and safety requirements.



Incorporating a robust Master Communication interface via SERCOS III, the controller delivers deterministic cycle times and seamless integration into multi-axis networks. It offers 2 Analog Outputs for precision control of downstream drive amplifiers and supports a Primary Encoder Option that accommodates IndraDyn, Hiperface, 1 Vpp, and TTL feedback protocols. The unit includes between 7–11 Digital Input Interfaces and up to 4 Digital Output Interfaces for direct connection to sensors, relays, and safety interlocks. Temperature management relies on natural convection cooling, eliminating the need for fans and reducing maintenance overhead.



Designed to operate reliably up to 1000 meters above sea level, the CSH01.1C-S3-ENS-ENS-NNN-L1-S-NN-FW includes an integrated safety option with starting lockout functionality to protect operators during start-up sequences. Its compact housing and standard mounting footprint simplify retrofit into existing control cabinets while ensuring compliance with industrial dust and debris requirements. Engineers benefit from a unified configuration toolset and scalable control logic libraries, making this controller an ideal choice for packaging lines, CNC machinery, and high-speed assembly systems seeking precision, uptime, and future expansion capability.

Technical Specifications

Analog Outputs
2

Master Communication
SERCOS III

Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-S3-ENS-ENS-NNN-L1-S-NN-FW.
