The CSH01.1C-S3-ENS-NNN-NNN-L1-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers advanced control system is engineered for single-axis automation tasks requiring high precision and flexible configuration. It operates as a SERCOS III master, offering deterministic, high-speed data transfer and native support for dual analog outputs. Measured velocity control cycles complete in 125 µs, ensuring rapid response to motion demands. The unit accommodates up to one safety technology module, delivering integrated protection with a With starting lockout safety option.
The controller delivers robust performance across a broad range of inputs and feedback devices. Native SERCOS III master communication provides sub-microsecond synchronization, while Encoder IndraDyn / Hiperface / 1 Vpp / TTL feedback ensures precise position tracking. The Maximum pulse width 100 ms parameter optimizes pulse train inputs, and typical inrush current peaks at 4 A without external suppression. Power draw remains minimal at 7,5 W, and firmware updates can be applied via the Must be ordered separately firmware module. A Standard control panel offers front-panel access to diagnostics and adjustments, and two analog outputs support process-level control loops.
Designed for seamless integration, the CSH01.1C-S3-ENS-NNN-NNN-L1-S-NN-FW slips easily into standardized cabinet layouts with a single safety slot. Its fully modular architecture permits rapid replacement of the control panel or firmware components, minimizing downtime. With precision feedback, built-in safety lockout, and deterministic fieldbus performance, this controller delivers reliable motion and process control across a wide spectrum of industrial automation applications.
Control pannel
Standard control panel
Firmware
Must be ordered separately
Master communication
SERCOS III
Maximum pulse width
100 ms
Option 1 (X4)
Encoder IndraDyn / Hiperface / 1 Vpp / TTL
Option 2 (X8)
Not equipped
Option 3 (X10)
Not equipped
Power consumption
7,5 W
Safety option (X41)
With starting lockout
Typ. Inrush current
4 A
