The Bosch Rexroth Indramat CSH01.1C-SE-EN1-MEM-MA1-L1-S-NN-FW from the CSH Advanced Controllers series features a SERCOS Interface master communication module and supports a HSF/RSF primary encoder option. It includes a single RS232 serial port, two analog outputs, and four digital outputs for flexible I/O integration. The controller achieves a rapid SERCOS cycle duration of 250 microseconds while offering fine-grained regulation through a current control range of 62.5 to 125 microseconds and a position control range of 250 to 500 microseconds. Its modular connectivity ensures compatibility with a broad range of servo drives and motion axes.
The compact control panel consumes just 1 watt of power, ensuring minimal energy overhead and predictable thermal performance. A dedicated 6-watt HSF/RSF encoder interface occupies the X4 slot, delivering high-resolution feedback for precise motion control. Configurable PWM frequency from 2 to 16 kHz in 2 kHz increments allows users to fine-tune switching characteristics for optimal noise and efficiency balance. An onboard analog input and modular firmware architecture—provided separately—simplify system updates, while multiple device variants cater to diverse power and interface requirements.
Safety is addressed through the optional L1 beginning lockout feature and an encoder emulator in the X8 slot, while the X10 slot offers an analog extension I/O for enhanced signal scalability. Operation requires valid licensing and adherence to specified ambient conditions to guarantee reliable performance. The CSH01.1C-SE-EN1-MEM-MA1-L1-S-NN-FW can be rapidly delivered by Wake Industrial to meet demanding project timelines.
Analog Outputs
2
Master Communication
SERCOS Interface
Primary Encoder Option
HSF/RSF
