CSH01.1C-SE-ENS-EN1-MA1-S2-S-NN-FW

CSH Advanced Controllers

  In Stock, Ships in 3-5 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

CSH01.1C-SE-ENS-EN1-MA1-S2-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers is an advanced control system designed for precise motion control in automated environments. It interfaces directly with IndraDrive drive sections via a plug-in architecture, simplifying cabinet layouts and minimizing wiring complexity. The module’s rugged construction and modular I/O scheme ensure durability and ease of maintenance in harsh industrial settings. Engineers will appreciate its seamless communication and scalability when integrated into existing machine architectures.



Equipped with Primary Encoder Option of Indradyn/Hiperface/1 Vpp/TTL and full compatibility with HSF/RSF encoder options, this controller delivers high-resolution position feedback. It supports Analog Outputs of 2 channels for closed-loop control and a flexible Master Communication bus via SERCOS Interface for deterministic multi-axis synchronization. The on-board Digital Inputs range of 7–11 channels plus an I/O Slot that can be configured as either input or output provides extensive machine interfacing without additional modules. A single configurable axis capability enables straightforward axis assignment, while Fieldbus Options including DeviceNet and CANopen ensure interoperability with a wide range of PLCs and HMI systems.



Integration into IndraDrive systems is streamlined by tool-free front connectivity and automatic parameter cloning, reducing commissioning time. The robust design and proven Rexroth motion algorithms deliver consistent performance and minimal downtime in critical applications. Ideal for high-speed packaging lines, paper printing machines, and food-grade production equipment, this controller combines precision, reliability, and flexibility in one compact package.

Technical Specifications

Analog Outputs
2

Master Communication
SERCOS Interface

Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-SE-ENS-EN1-MA1-S2-S-NN-FW.
