CSH01.1C-SE-ENS-EN2-EN2-S1-S-NN-FW, manufactured by Bosch Rexroth Indramat, is part of the CSH Advanced Controllers family and offers a robust drive control interface for demanding automation tasks. This advanced control system features a high-speed SERCOS Interface master communication backbone and supports a range of encoder protocols for precision feedback. Designed to integrate seamlessly into modern drive architectures, it provides both high reliability and rapid response to control inputs. The compact design accommodates two Analog Outputs and delivers performance tailored to dynamic industrial environments.
In detailed specification, the unit provides 2 distinct Analog Outputs for versatile signal routing and flexible process control. Master communication is handled via a SERCOS Interface for deterministic, real-time data exchange. The primary encoder interface supports multiple protocols—Indradyn, Hiperface, 1 Vpp, and TTL—ensuring compatibility with a wide array of feedback devices. Cycle frequencies of 4 kHz, 8 kHz, 12 kHz, and 16 kHz allow users to optimize the control loop bandwidth to match machine dynamics. Embedded CANopen connectivity via compatible modules (HCC06, CD X61) further extends communication options, while the advanced ENS encoder system module offers plug-and-play installation.
Installation and commissioning are simplified by front-end plug-in modules that clip onto the control frame without tools. The CSH01.1C-SE-ENS-EN2-EN2-S1-S-NN-FW delivers short cycle times for velocity, current, and position loops, enabling rapid reaction to process changes and improving overall system throughput. With its modular architecture, high-speed feedback interfaces, and proven industrial reliability, this controller is ideal for paper machinery, woodworking lines, packaging systems, and other high-demand applications where precision and uptime are critical.
Analog Outputs
2
Master Communication
SERCOS Interface
Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
