CSH01.1C-SE-ENS-EN2-NNN-L2-S-XP-FW, Bosch Rexroth Indramat, CSH Advanced Controllers delivers a compact yet powerful Advanced Control System optimized for high-performance motion applications. The unit measures for minimal panel footprint while providing a flexible architecture ready for customization. Equipped with an intuitive H1 slot for control-panel interface, this controller supports seamless field integration without sacrificing accessibility. Firmware installation is simplified through a dedicated memory-card slot, ensuring rapid commissioning of application-specific code.
In-depth tech specs include Analog Outputs: 2 channels for precision current or voltage signaling, and a Master Communication: SERCOS Interface offering deterministic real-time motion control. The controller accepts a primary encoder option of Indradyn, Hiperface, 1 Vpp, or TTL feedback, accommodating a broad range of motor-feedback protocols. A Control Panel Interface: H1 slots facilitates local operator dialogs, while a Memory Card Slot: dedicated secures firmware and parameter archives. Natural airflow is managed by an internally engineered Cooling Method: natural convection, eliminating moving parts for silent operation. Separate firmware download requirements ensure version traceability, and robust connection design protects against reverse polarity at supply terminals.
Engineered for series integration, this CSH controller easily pairs with Bosch Rexroth digital AC servo motors and drive modules, forming a scalable multi-axis system. Its rugged design and convection-cooling reliability minimize maintenance and extend service intervals in harsh environments. Application benefits include synchronized high-speed positioning, simplified safety-circuit integration, and fast replacement workflows, making it ideal for packaging, printing, or robotic handling lines.
Analog Outputs
2
Master Communication
SERCOS Interface
Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
