CSH01.1C-SE-ENS-ENS-NNN-S1-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

CSH01.1C-SE-ENS-ENS-NNN-S1-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers is a high-performance motion control unit engineered for precision automation. It features a dual-analog output architecture delivering 2 independent channels and supports a flexible Indradyn/Hiperface/1 Vpp/TTL primary encoder option. Communication is handled via the embedded SERCOS Interface master link for deterministic data exchange. This controller is tailored for integration into complex drive networks, combining compact dimensions with robust feature sets.



Engineered for industrial environments, the unit operates reliably across an Operating Temperature range of 0 … 40 °C and can be stored safely between -20 … 80 °C. It is qualified for mounting at elevations up to 1000 m above sea level without performance degradation. Safety is enhanced by built-in Safe Motion technology at the X41 interface, while a dedicated Memory Card Slot at X7 enables local parameter backup and firmware updates. A front-panel port at H1 supports an optional control panel interface for on-site diagnostics and tuning.



Designed for seamless integration, the controller aligns with Bosch Rexroth’s ecosystem, easing commissioning through parameter cloning and SERCOS-based synchronization. Its dual Analog Outputs and multi-channel digital I/O ports accommodate diverse sensor and actuator configurations with minimal external hardware. Rugged construction and conformal-coated electronics ensure reliability in demanding applications, from high-speed packaging to precision machine tools. The CSH01.1C-SE-ENS-ENS-NNN-S1-S-NN-FW delivers a compact, scalable solution that maximizes uptime and simplifies system expansion.

Technical Specifications

Analog Outputs
2

Master Communication
SERCOS Interface

Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
