The CSH01.1C-SE-ENS-NNN-MA1-L1-S-NN-FW from Bosch Rexroth Indramat is part of the CSH Advanced Controllers series and serves as a highly configurable control unit for motion and drive applications. It features a SERCOS interface master communication for deterministic real-time networking, an Encoder IndraDyn/Hiperface/1 Vpp/TTL primary encoder option for precise feedback, and an Analog I/O extension (Option 3) to expand signal processing capabilities. Designed to integrate seamlessly with IndraDrive systems, it provides flexible I/O management and robust drive control in both standardized and high-end automation environments.



In terms of technical specifications, the CSH01.1C-SE-ENS-NNN-MA1-L1-S-NN-FW operates on a Standard control panel configuration, with firmware that must be ordered separately to match specific application requirements. The unit supports a maximum pulse width of 100 ms and maintains a low power consumption of 7.5 W during normal operation, with a typical inrush current of 4 A on startup. Safety is ensured by an integrated starting lockout (X41), preventing unintended drive activation. Its encoder interface (X4) accommodates IndraDyn, Hiperface, 1 Vpp, and TTL signals, while the analog I/O extension processes additional sensor inputs and generates precise analog outputs for downstream devices.



Built for durability and future-proofing, this controller offers broad compatibility with existing Bosch Rexroth drive components and can be configured to adapt to evolving automation needs without full system replacement. The high-quality construction of the analog I/O extension ensures reliable signal conditioning under industrial conditions, and the modular firmware approach allows tailored functionality. By leveraging certified safety features and deterministic SERCOS communication, the CSH01.1C-SE-ENS-NNN-MA1-L1-S-NN-FW delivers enhanced efficiency, precise motion control, and scalable performance—making it an ideal choice for complex manufacturing and process automation applications.

Technical Specifications

Control pannel
Standard control panel

Firmware
Must be ordered separately

Master communication
SERCOS interface

Maximum pulse width
100 ms

Option 1 (X4)
Encoder IndraDyn / Hiperface / 1 Vpp / TTL

Option 2 (X8)
Not equipped

Option 3 (X10)
Analog I/O extension

Power consumption
7,5 W

Safety option (X41)
With starting lockout

Typ. Inrush current
4 A
