The CSH01.1C-SE-ENS-NNN-MA1-L2-S-NN-FW from Bosch Rexroth Indramat is a cornerstone of the CSH Advanced Controllers family, designed for precision motion control in demanding industrial environments. This sophisticated unit integrates a Standard control panel for direct parameter access and features a Firmware must be ordered separately model that allows tailored software configurations. Communication is handled via a Master communication SERCOS interface, ensuring deterministic real-time networking for multi-axis synchronization. Its compact design draws only 7,5 W of power while delivering reliable performance under continuous operation.
The controller supports a range of expansion options to match diverse automation requirements. An integrated Encoder IndraDyn / Hiperface / 1 Vpp / TTL channel (Option 1 X4) provides high-resolution feedback, while the Analog I/O extension (Option 3 X10) accommodates precise control of external drives. Option 2 (X8) is Not equipped, simplifying system selection when encoder expansion is not required. The Maximum pulse width 100 ms specification and a Typ. Inrush current 4 A design ensure consistent signaling and protect against electrical stress during start-up sequences.
Safety and reliability are built in through a Safe torque off (SIL3 / cat 3 PL e) option (X41) that meets the highest functional safety standards. The controller’s low standby power draw and optional firmware deliver flexibility for both new installations and retrofit projects. Together, these features make the CSH01.1C series an optimal solution for high-performance servo applications, robotics, and multi-axis gantry systems.
Control pannel
Standard control panel
Firmware
Must be ordered separately
Master communication
SERCOS interface
Maximum pulse width
100 ms
Option 1 (X4)
Encoder IndraDyn / Hiperface / 1 Vpp / TTL
Option 2 (X8)
Not equipped
Option 3 (X10)
Analog I/O extension
Power consumption
7,5 W
Safety option (X41)
Safe torque off (SIL3 / cat 3 PL e)
Typ. Inrush current
4 A
