The Bosch Rexroth Indramat CSH01.1C-SE-ENS-NNN-MD2-NN-S-NN-FW from the CSH Advanced Controllers series features Master Communication: SERCOS Interface and supports a Primary Encoder Option: Indradyn/Hiperface/1 Vpp/TTL with 2 Analog Outputs. This compact unit measures 103 x 49.5 x 241 mm and operates reliably across an ambient temperature range of 0 to +40 °C. Designed for industrial environments with an IP20 protection class, it offers a single relay contact and dedicated single-axis drive control for precise motion operations.
Engineered for seamless integration, the control section includes a clear single-line display and switchable frequency settings for versatile machine compatibility. Robust digital outputs and analog inputs enable real-time feedback loops, while the standard relay contact simplifies safety interlocks. Storage tolerances span –20 to +80 °C, ensuring durability in fluctuating conditions and maintenance cycles. Its user-friendly configuration interface supports pre-commissioning setup, reducing on-site tuning time.
Ideal for handling systems, printing equipment, and robotic assemblies, the CSH01.1C-SE-ENS-NNN-MD2-NN-S-NN-FW delivers high-speed synchronization and failsafe communication. Backed by Bosch Rexroth Indramat’s legacy of support and Wake Industrial’s technical assistance, this controller maximizes uptime and performance in demanding automation applications.
Analog Outputs
2
Master Communication
SERCOS Interface
Primary Encoder Option
Indradyn/Hiperface/1 Vpp/TTL
