CSH01.3C-ET-EN2-ENS-CCD-S2-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers. The CSH01.3C-ET-EN2-ENS-CCD-S2-S-NN-FW controller from Bosch Rexroth Indramat belongs to the CSH Advanced Controllers series and delivers centralized drive processing in a compact control section. It operates as a MultiEthernet master communication node, orchestrating networked axes with deterministic timing. The unit accommodates two dedicated encoder modules and a cross communication module, all hot-pluggable for rapid field service. A built-in safety module implements safe motion functions to meet modern machine safety requirements.
The control section features a MultiEthernet master communication interface and supports a Primary Encoder Option of EnDat 2.1/1 Vpp/TTL in slot 1 plus an IndraDyn Hiperface encoder in slot 2. Two Analog Outputs deliver precise 0…10 V signals for closed-loop feedback control. Convection cooling ensures maintenance-free thermal management without fans, while a rugged design limits control section mounting cycles to 20 removals/mountings to preserve connector integrity. Firmware and type-plate data provide full traceability of serial number, firmware version, and configuration, simplifying audits and upgrades.
Engineered for seamless integration with Bosch Rexroth power sections, the CSH01.3C-ET-EN2-ENS-CCD-S2-S-NN-FW offers modular expandability via plug-in encoder, communication, and safety modules. Its deterministic MultiEthernet backbone streamlines high-speed synchronization across multi-axis systems, boosting throughput in packaging, material handling, and machine tool applications. The combination of convection cooling, safe motion, and standardized type-plate identification delivers a highly reliable, service-friendly platform for modern automated production lines.
Analog Outputs
2
Master Communication
MultiEthernet
Primary Encoder Option
EnDat 2.1/1 Vpp/TTL
