CSH01.3C-ET-EN2-MA1-CCD-L2-S-NN-FW

The CSH01.3C-ET-EN2-MA1-CCD-L2-S-NN-FW, manufactured by Bosch Rexroth Indramat, is part of the CSH Advanced Controllers family and represents a high-performance control section for demanding industrial automation. This advanced control system features an integrated MultiEthernet master communication interface that supports Sercos III, EtherCAT, PROFINET, and Sercos networks natively. The unit’s Primary Encoder Option of EnDat 2.1/1 Vpp/TTL ensures precision feedback for servo applications. Additionally, the controller provides 2 analog outputs for flexible signal integration.

The CSH01.3C-ET-EN2-MA1-CCD-L2-S-NN-FW offers STO support (Safe Torque Off) via an optional safety module, implementing a two-channel opto-coupler blockade to guarantee a no-torque state when required. Modular expandability includes a dedicated encoder module and an analog I/O extension module, each designed for rapid field installation. A cross communication module enables direct data exchange between controllers without PLC intervention, reducing cycle times and simplifying network topology. Compatibility with a standard control panel allows local HMI integration, while firmware versions are easily identified and loaded based on the type plates on both controller and panel.

Engineers will appreciate the seamless integration of MultiEthernet in heterogeneous networks, delivering open communication and uniform diagnostics across all connected drives and I/O devices. The drive-integrated STO function enhances system reliability and safety compliance, minimizing external hardware and wiring complexity. This versatile control section is ideal for machine builders seeking precise motion control, functional safety, and scalable I/O in packaging, assembly, and material-handling applications.
