The Bosch Rexroth Indramat CSH01.3C-ET-EN2-MA1-CCD-S2-S-NN-FW controller is part of the CSH Advanced Controllers series and features a high-performance MultiEthernet master communication configuration alongside a primary encoder option of EnDat 2.1/1 Vpp/TTL and 2 analog outputs. This advanced control section is designed to serve as the central processing unit in demanding automation environments, making it ideal for handling and mounting systems, packaging and food machines, and printing machinery. Its robust communication interface and precise encoder support enable seamless integration into modern industrial networks, ensuring accurate motion control and data exchange at high speeds.



Built around a modular architecture, the CSH01.3C-ET-EN2-MA1-CCD-S2-S-NN-FW control section comes factory fitted with a suite of plug-in modules, including an encoder EnDat 2.1 module, an analog I/O extension module, a cross communication module, a MultiEthernet module, and a safety module offering safe motion support. The system delivers 2 analog outputs for flexible signal processing and supports the MultiEthernet protocol for real-time data transfer. The EnDat 2.1/1 Vpp/TTL encoder interface ensures high-resolution feedback, minimizing positioning errors and enhancing the fidelity of motion control loops.



This controller is compatible with a standard control panel and mounts directly onto a power section that provides DC power. Installation and removal should be performed only by trained personnel, guided by the comprehensive user manual supplied by Bosch, which includes all relevant safety precautions. Designed for vertical installation, the unit features passive convection cooling to dissipate heat naturally without fans, though external cooling fans or air conditioning can be employed to further improve thermal management. The combination of modular expandability, reliable passive cooling, and industry-grade communication standards makes the CSH01.3C-ET-EN2-MA1-CCD-S2-S-NN-FW an efficient and durable solution for complex industrial automation applications.

Technical Specifications

Analog Outputs
2

Master Communication
MultiEthernet

Primary Encoder Option
EnDat 2.1/1 Vpp/TTL
