CSH01.3C-ET-EN2-MEM-CCD-NN-S-NN-FW

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The CSH01.3C-ET-EN2-MEM-CCD-NN-S-NN-FW, Bosch Rexroth Indramat, CSH Advanced Controllers unit is a high-performance control section designed for precision motor management. It operates at the heart of Bosch’s IndraDrive CSH Control System, providing robust signal processing and module-based scalability. Each controller ships with three distinct type plates—two on the control section and one on the power section—detailing serial numbers, firmware versions, and key parameters. Operators must verify these plates upon delivery to ensure correct identification, prevent improper installation, and maintain warranty validity.



In its standard configuration, the controller delivers 2 Analog Outputs and supports Primary Encoder Option: EnDat 2.1/1 Vpp/TTL for absolute position feedback. Communication is handled via a MultiEthernet master interface, backed by a Cross Communication Module compliant with IEEE 802.3 and offering 2 Ethernet Interfaces for daisy-chain or parallel network topologies. An onboard Encoder Emulation Module generates both absolute and incremental signals without an External Power Supply, and all encoder lines are Galvanically Isolated to prevent ground loops. A Standard Control Panel can be connected while the unit is powered down for configuration and diagnostics, ensuring user safety and preventing misrecognition during power-up.



Engineered for seamless integration into automated machinery, this CSH controller combines modular connectivity and hardened electronic isolation for maximum uptime. Its broad encoder support and dual-Ethernet topology simplify fieldbus integration and multi-axis synchronization. Built-in safeguards and clear type-plate documentation guarantee reliable operation in demanding industrial environments.

Technical Specifications

Analog Outputs
2

Master Communication
MultiEthernet

Primary Encoder Option
EnDat 2.1/1 Vpp/TTL

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.3C-ET-EN2-MEM-CCD-NN-S-NN-FW.
