CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CSH01.3C-PB-EN2-NNN-CCD-NN-S-NN-FW controller from the CSH Advanced Controllers series is an advanced control system engineered for precise motion and process control. It features PROFIBUS master communication and supports a primary encoder option of EnDat 2.1/1 Vpp/TTL for high-resolution feedback. The compact section must be mounted and transported using proper equipment to prevent mechanical stress, and it does not support hot-plug operations on the control panel. A modular design allows optional cross-communication support to integrate additional network nodes without expanding the chassis.



Designed for high-performance installations, this unit provides 2 analog outputs and consumes 8.5 kW at 24 VDC under maximum output load, including its control panel and multimedia card. Communication versatility is delivered via a RS-232 serial interface with a circular MiniDin eight-pole connector, while the cross-communication port adheres to IEEE 802.3 Ethernet standards. Terminals X31 and X32 feature fully isolated inputs/outputs to protect against ground loops and electrical interference in industrial environments. Additionally, the system benefits from a one-year backup support program, ensuring rapid diagnostics and replacement planning in the event of a failure.



Integration into existing architectures is simplified through industry-standard interfaces and configurable modules, enabling seamless extension of control channels and encoder network topologies. The controller’s robust construction and enforced discharge procedures minimize downtime and protect sensitive electronics during maintenance. Ideal for demanding automated production lines, the CSH01.3C-PB-EN2-NNN-CCD-NN-S-NN-FW ensures reliable precision, scalability, and long-term operational stability.

Technical Specifications

Analog Outputs
2

Master Communication
PROFIBUS

Primary Encoder Option
EnDat 2.1/1 Vpp/TTL
