R911297121 (CSH01.1C-PB-EN1-NNN-NNN-L1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911297121 (CSH01.1C-PB-EN1-NNN-NNN-L1-S-NN-FW) is a Bosch Rexroth CSH01 series ADVANCED control section for the IndraDrive system, designed for managing electric motor operations in applications requiring high performance and dynamic response. This unit integrates a PROFIBUS communication module for cyclical data exchange with networked devices and supports Resolver and HSF Encoder Evaluation with DC 8V or AC 18.2V peak-peak signals. It features two analog outputs and supports HSF/RSF as the primary encoder option. The integrated starting lockout function prevents unintended motor startup, complying with EN60204-1 stop category 0. Configuration, address setting, and error memory access are available via the standard operator panel.

Technical Specifications

Product Type
Rexroth IndraDrive drive controller

Category
Control Sections

Range
ADVANCED

Communication Module
PROFIBUS

Software Compatibility
IndraWorks

Integrated Interface
Resolver and HSF Encoder Evaluation

Supply Voltage
DC 8V or AC 18.2V peak-peak

Safety Technology Feature
Starting Lockout

Compliance
STOP category 0 according to EN60204-1

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-PB-EN1-NNN-NNN-L1-S-NN-FW.
