R911297122 (CSH01.1C-PB-EN2-NNN-NNN-L1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 23 Seconds

The Bosch Rexroth MPN R911297122 (CSH01.1C-PB-EN2-NNN-NNN-L1-S-NN-FW) is a single-axis drive controller designed for managing electrical motors. It consists of a control section, which should not be installed or removed more than 20 times, and a power section. The controller features Protective Extra Low Voltage for secure connections to devices with basic insulation such as PCs and display units. Master communication is implemented via PROFIBUS, and the controller includes two analog outputs as well as a primary encoder option supporting EnDat 2.1, 1 Vpp, or TTL interfaces. A standard control panel provides operational status and warnings on a single-line display and is operated with four function keys. The integrated Starting Lockout safety mechanism prevents unintentional motor activation.

Technical Specifications

Plug-In section of drive controller
Yes

Maximum Mountings/Dismountings
20 times

Communication
Via PROFIBUS network

Encoder Evaluation Interface
Suitable for 5V supply encoder systems

Control Panel
Standard, single line display

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon
AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-PB-EN2-NNN-NNN-L1-S-NN-FW.
Exchange
exchange payment Want to sell your CSH01.1C-PB-EN2-NNN-NNN-L1-S-NN-FW?
