R911297125 (CSH01.1C-PB-EN1-EN2-NNN-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-EN2-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911297125 (CSH01.1C-PB-EN1-EN2-NNN-L1-S-NN-FW) is an industrial controller by Rexroth Indramat designed for precise management of electric motors in automated systems. It features a robust housing suited for demanding environments and utilizes forced air cooling with an internal heatsink and air blower. Power requirements include a 24 V power supply, 7.5 W standard consumption, and 4 A inrush current. The unit provides 7–11 digital input connectors, up to 2 digital output connectors, and 2 analog outputs. Communication is supported via PROFIBUS, and the primary encoder interface accepts HSF/RSF signals. Control cycle times are 125 µs for current, 250 µs for velocity, and 500 µs for position regulation. Firmware is not included with the hardware.

Technical Specifications

Rexroth Indramat
Producer

Housing Material
Metal

Environmental Friendliness
High

Recycling Option
Available

Firmware Module
Sold Seperately

Forced Air-Cooling Mechanism
Included

Power Consumption
7.5 Watts

Inrush Current
4 Amperes

Power Supply Compatibility
24-volt

Digital Input Connectors
7 to 11

Digital Output Connectors
0

Cycle Time for Current Control
125 microseconds

Cycle Time for Velocity Control
250 microseconds

Cycle Time for Position Control
500 microseconds

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-PB-EN1-EN2-NNN-L1-S-NN-FW.

Exchange

Want to sell your CSH01.1C-PB-EN1-EN2-NNN-L1-S-NN-FW?
