The R911298701 (CSH01.1C-SE-EN1-NNN-MA1-L1-S-NN-FW) is a digital control section designed for integration with a compatible power section to form a complete IndraDrive controller. This unit features two analog outputs and provides master communication via the SERCOS interface, suitable for high-speed, real-time automation systems. The control section supports an HSF/RSF encoder module, includes an analog I/O extension, and incorporates a safety module for starting lockout functionality. It is compatible with a standard control panel featuring a digital display and four operation keys, but does not support hot plug operations. Firmware is installed according to application-specific requirements.

Technical Specifications

Product Type
Digital Control Section

Firmware
Sold Separately

Control Panel Compatibility
Standard

Display Type
Digital

Communication Protocol Supported
SERCOS

Communication Speed
Up to 16 Mbit/s

Encoder Supported
HSF/RSF Module

Hardware Modules Installed
Analog I/O Extension, Safety Module

Safety Feature
Starting Lockout

Real-Time Control and Automation
Supported

Control Panel Hot Plug Support
Not Supported

Fiber Optics Communication
Supported

Twisted Pair Communication
Supported

Coaxial Cable Communication
Supported

Industrial Applications
Machine Tools, Robots, Packaging Machinery
