R911298702 (CSH01.1C-SE-EN2-NNN-MA1-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-NNN-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911298702 (CSH01.1C-SE-EN2-NNN-MA1-L1-S-NN-FW) is a Bosch Rexroth CSH01.1C control section utilized in drive controller systems for applications such as printing, paper processing, packaging, and robotics. It features two analog outputs, master communication via SERCOS interface, and a primary encoder option supporting EnDat 2.1, 1 Vpp, and TTL signals. The device measures over 103mm x 241mm x 49.5mm and is cooled by natural convection, requiring installation in a location with adequate air passage. The standard control panel allows configuration, and multi-encoder interface compatibility supports a range of motor feedback systems. Firmware is ordered separately and must be installed to enable device operation.

Technical Specifications

Application
Printing, Paper Processing, Packaging, Robotics

Component of
Drive Controller

Size
103mm x 241mm x 49.5mm

Cooling Method
Natural Convection

Firmware
Ordered Separately

Support for Motor Encoders
Yes through Multi-Encoder Interface

Interface
SERCOS

Control Panel Included
Yes

Delivery
To Desired Address

After Sales Services
Available
