R911298704 (CSH01.1C-SE-EN2-NNN-MA1-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-NNN-MA1-S1-S-NN-FW Series Image

In Stock, Ships in 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911298704 (CSH01.1C-SE-EN2-NNN-MA1-S1-S-NN-FW) control section from Bosch Rexroth integrates advanced capability including safety technology I/O at the X41 interface, requiring a secure starting lockout to prevent unintentional startup. The unit operates with temperatures that may exceed 60°C during and after use. It features spring terminals, screw terminal blocks, and distinct interfaces for control and engineering. Two differential analog outputs are provided at the X26 point, with master communication supported via SERCOS Interface and a primary encoder interface compatible with EnDat 2.1/1 Vpp/TTL. The unit requires external voltage connections at X31.8 and X31.9, and is designed for use with specified battery types. Firmware is not included and must be sourced separately.

Technical Specifications

Operating Temperature
Over 60°C

Connection Points
Spring terminals and screw terminal blocks

Relay Contact
Type 2, 1A and 24VDC

Voltage Connection Points
X31.8 and X31.9

Firmware
Procured separately

Panel Fitting
Standard control panel fitting

Protection
ESD Protection

Part Category
C3 according to IEC 61800-3

Packaging
Custom rugged packaging
