R911306768 (CSH01.1C-SE-EN2-EN2-NNN-L1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth CSH series control unit, MPN R911306768 (CSH01.1C-SE-EN2-EN2-NNN-L1-S-NN-FW), provides two analog outputs and supports encoder evaluation for compatible 5V encoders, including EnDat 2.1, 1 Vpp, and TTL types. It communicates with advanced control systems using a SERCOS master interface over fiber optic cables to minimize electromagnetic interference. The integrated Starting lockout safety module is designed according to EN 60204-1. The control panel is equipped with a single-line display and four keys for straightforward setting adjustment. The unit supports flexible switching frequencies and allows mounting and dismounting from the drive controller up to 20 times.

Technical Specifications

Product Name
Bosch Rexroth CSH Control Section

Encoder Interface
2 interfaces, 5V supply

Communication Module
SERCOS master

Connection Method
Fiber optic cables

Firmware Support
Yes (Order separately)

Control Panel
Standard, Single-line display, Four operating keys

Switching Frequencies
2kHz, 4kHz, 8kHz, 12kHz, 16kHz

Mounting
Mountable and dismountable up to 20 times
