R911308110 (CSH01.1C-SE-EN1-ENS-NNN-S1-S-NN-FW)
CSH Advanced Control System
Call For Quote
1 Year Warranty Included
Free Ground Shipping
Or speak to a sales representative for additional information:
1-888-551-3082
[email protected]
R911308110 is part of the CSH Advanced Control System Series by Indramat Controls.
Technical Specifications
Digital inputs
7 to 11
Serial interface
RS232
Connection module
SERCOS interface
Safety option
S1 (safety technology I/O)
Analog input
1
Digital outputs
4
Cycle time options
125-250, 62.5-125, 250-500 microseconds
Maximum installation and unmounting times
20
Minimum cycle time (SERCOS variant)
250 microseconds
X4 slot
HSF/RSF encoder (6 W consumption)
Operating environment
Industrial
Programmable firmware
Yes (ordered separately)
Required interconnection
0.75 - 1.50 mm twisted wire
Input voltage
24 V
Operating temperature range
Not specified
Dimensions
49.5 mm (depth), 103 mm (width), 244 mm (height)
X8 slot
IndraDyn/hiperface
X10 slot
Empty
Vendor
Indramat USA
Common Misspellings
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the CSH01.1C-SE-EN1-ENS-NNN-S1-S-NN-FW.
