The Bosch Rexroth R911308113 (CSH01.1C-SE-ENS-EN1-MEM-S1-S-NN-FW) is a configurable control section from the CSH series designed for single-axis control applications. It features a four-button keypad and digital display for system monitoring, supports two analog outputs, and utilizes the SERCOS interface for master communication. The primary encoder options include Indradyn, Hiperface, 1 Vpp, and TTL. This unit operates with a base power consumption of 7.5 W, reaching up to 23.5 W with additional hardware. Connection to a power section is required. The device relies on convection cooling and adequate installation spacing. Safety I/O is provided via a dedicated safety module. Firmware selection must match the intended application.

Technical Specifications

Application
Single Axis Control

Device Type
Configurable

Control Panel Compatibility
Standard

Hot Plug Support
No

Control Panel Features
Digital Display, Four-button Keypad

Power Source
Power Section

Device Power Consumption
7.5 Watts

Additional Hardware Power Consumption
Variable

Encoder Emulation Module Power Consumption
2 Watts

Installed Encoder Modules Power Consumption
6 Watts each

SERCOS Communication Module Power Consumption
2 Watts

Total Power Consumption
23.5 Watts

Cooling Method
Convection

Safety Technology Support
Yes

Firmware
Selectable

Qualified Personnel Requirement
Yes

Approved Accessories Requirement
Yes

Usage Conditions
Permitted Operating Conditions only.
