R911308270 (CSH01.1C-PB-EN1-EN1-NNN-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-EN1-NNN-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911308270 (CSH01.1C-PB-EN1-EN1-NNN-NN-S-NN-FW) is a CSH01.1 control section for IndraDrive systems. It integrates a PROFIBUS master communication interface and accommodates modular expansion, including two encoder modules (HSF/RSF) occupying the first and second slots, with the third slot empty; the safety module slot is unpopulated. The unit provides two analog outputs and requires a 24V DC supply, draws 7.5W power, and has a typical inrush current of 4A. Serial communication is established via a single RS-232 interface. The switching frequency is adjustable from 2 kHz up to 16 kHz. Device identification is managed with integrated type and firmware plates. Installation and operation should be performed by qualified technical personnel.

Technical Specifications

Type
Advanced Control Section

Configurability
Configurable

Master Communication
Profibus

Safety Module
Not Installed

Encoder Modules
2 (slot 1 and slot 2)

Optional Module Slot 3
Vacant

Input
24 Volts DC

Power Consumption
7.5 Watts

Inrush Current Value
4 Amps

Additional Power per Encoder Module
6 Watts

Serial Port
Integrated RS-232

Supported Switching Frequencies
2 to 16 kilohertz in steps of 2 kilohertz

Firmware
Type Plate Attached

Installation and Operation
Qualified Technical Personnel.
