R911308392 (CSH01.1C-SE-EN1-MEM-MA1-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-MEM-MA1-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth drive controller module R911308392 (CSH01.1C-SE-EN1-MEM-MA1-NN-S-NN-FW) is configured with a control section type CSH01.1 and supports current control durations of 62.5–125 μs, speed control of 125–250 μs, and position control of 250–500 μs. It includes a master SERCOS interface for communication, HSF/RSF encoder support as the primary encoder option, two analog outputs, one analog input, one RS232 serial interface, four digital outputs, and seven to eleven digital inputs. The integrated encoder emulator, SERCOS cycle time of 250 ms, and analog extension module in the X10 slot enhance system versatility. Power consumption for the control section is 7.5 W. The physical dimensions are 103 mm × 241 mm × 49.5 mm. This module is not intended for use on residential low-voltage public distribution mains.

Technical Specifications

Encoder Slots
HSF/RSF(X4), Encoder Emulator(X8)

Digital Outputs
4

Current Control Durations
62.5 to 125 microseconds

Position Control durations
250 to 500 microseconds

Speed Control Durations
125 to 250 microseconds

Power Consumption
7.5 watts

Digital Inputs
7 to 11

Master Module
SERCOS interface communication module

Extension Slot
Analog extension in X10

Residential Low-voltage Public Distribution Mains Compatibility
No

Dimensions
Width: 103 mm, Height: 241 mm, Depth: 49.5 mm

SERCOS Cycle Time
250 milliseconds.
