R911308393 (CSH01.1C-SE-EN1-MEM-MA1-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-MEM-MA1-S1-S-NN-FW Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911308393 (CSH01.1C-SE-EN1-MEM-MA1-S1-S-NN-FW) is a Bosch Rexroth single-axis programmable drive controller designed for integration in various automation systems. It features an analog extension in the X10 slot with two analog outputs, and supports the SERCOS interface for master communication with a minimum cycle time of 250 microseconds. The X4 slot provides four digital outputs, a relay contact, and accommodates HSF/RSF encoder feedback. Dimensions for this module are 103mm width, 49.5mm depth, and 244mm height. Configurable parameters include velocity, current, and cycle time. The model incorporates the S1 safety function. Adherence to specified environmental and safety requirements is mandatory.

Technical Specifications

Analog Extension
In X10 Slot

Firmware
Flexible Type, Ordered Separately

Digital Outputs
4 on X4 Slot

Relay Contact
Available on X4 Slot

Encoder
HSF/RSF on X4 Slot

SERCOS Model
Yes

Minimum Cycle Time
250 Microseconds

Environmental Limit
Must be Used Within Specified Limits

Width
103 mm

Depth
49.5 mm

Height
244 mm

Digital Inputs
7-11 programmable

Safety Feature
S1 (Safety Technology I/O)

Control Panel
Intuitive

Encoder Emulator
On X8 Port

Velocity Adjustment
125-250 Microseconds

Current Adjustment
62.5-125 Microseconds

Cycle Time Function Adjustment
250-500 Microseconds

Global Distribution
By Indramat USA.
