R911308804 (CSH01.1C-SE-EN1-EN2-MA1-NN-S-NN-FW)

CSH Advanced Controllers

  In Stock, Ships in 3-5 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth MPN R911308804 (CSH01.1C-SE-EN1-EN2-MA1-NN-S-NN-FW) is a single-axis control section for IndraDrive drive systems, supporting SERCOS communication via fiber optic cables with configurable data rate and transmission power. It evaluates resolver and HSF encoder signals, suitable for supply voltages of DC 8V, AC 18.2V peak-to-peak, or 5V encoders. The unit includes an Analog I/O Extension, providing two analog outputs to extend channel availability. It is intended for industrial environments, with specific interference suppression required in residential installations.

Technical Specifications

Product Range
ADVANCED

Use Case
Industrial Only

Control Section Type
Single-Axis

Interface
Resolver and HSF encoder evaluation

Encoder Supply Voltage
DC 8V or AC 18.2V peak-peak

Standard Encoder Evaluation Interface Supply Voltage
5V

Communications System
SERCOS

Connections to Higher-Level Control Units
Yes

Connection Method
Fiber Optics Cables

Adjustable Data Rate and Transmission Power
Yes

Analog I/O Extension
Present

Standard Control Panel
Single-Line Display and Four Keys

Measures of Interference Suppression
Required in Residential Areas
