R911308997 (CSH01.1C-SE-EN1-EN2-MA1-S1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 34 Seconds

The Bosch Rexroth MPN R911308997 (CSH01.1C-SE-EN1-EN2-MA1-S1-S-NN-FW) functions as a single-axis control unit within the IndraDrive ADVANCED line. It features both Resolver and HSF encoder interfaces, supporting encoders requiring DC 8V, AC 18.2V peak-peak, or 5V supply, and is compatible with encoders for MHD and MKD motors as well as square wave types. The device includes two analog outputs via an Analog I/O Extension, a dedicated I/O safety module providing drive interlock and motion direction functions, and is equipped with a SERCOS master communication interface for integration with higher-level controllers. System setup and diagnostic functions are accessible through a control panel with a single-line display and four keys.

Technical Specifications

Product
IndraDrive single-axis control section

Configurable Device
Yes

Interface
Resolver and HSF encoder evaluation interface

Safety Technology
Yes; offers application-related safety functions

Communication Module
SERCOS master

Connectivity
Fiber optic cables
