R911309543 (CSH01.1C-NN-EN1-MEM-MA1-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-EN1-MEM-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911309543 (CSH01.1C-NN-EN1-MEM-MA1-L1-S-NN-FW) is a configurable control section designed for dual-axis applications, supporting switching frequencies from 2 kHz to 16 kHz. It operates with an external supply voltage and includes one analog input and two analog outputs. The unit is not equipped for master communication. An optional module enables operation with HSF/RSF encoder types, with supply voltage requirements between 8 VDC and 18 VAC. Data storage is facilitated via a memory card in the X7 slot. The device features a relay contact rated for 30 VDC with a 10 ms timing for both pickup and dropout. It incorporates a MEM interface encoder emulator for signal evaluation by the control unit, and its signal processing affects output duty cycle and period. Mounting is limited to 20 cycles, and commissioning is required prior to operation.

Technical Specifications

Switching Frequencies
2kHz, 4kHz, 8kHz, 12kHz, 16kHz

Supply Voltage Connection
External

Analog Input Number
1

Analog Output Number
2

Axes
2

Master Communication
Not Supported

Optional Module
HSF/RSF encoder

Encoder Supply Voltage
18VAC_peak-to-peak, 8VDC

Cutoff frequencies for HSF and Resolver operation
100kHz, 18kHz

Compatibility
Not compatible with VCP01.2 comfort control panel

Digital Inputs
2 Type 2, 2 Type 3

Relay Contact Voltage Load Capacity
30VDC

Relay Pickup Delay
10ms

Relay Dropout Delay
10ms

Interface Encoder Emulator
MEM

Mounting/Unmounting Limit
20 times

Startup Process Requirement
Commissioning

Output Signal Influence
Signal Processing Activity

Shipping Availability
Worldwide
