R911309544 (CSH01.1C-NN-EN1-MEM-MA1-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-EN1-MEM-MA1-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911309544 (CSH01.1C-NN-EN1-MEM-MA1-S1-S-NN-FW) is a Bosch Rexroth advanced control section designed for interface via RS-232 through an eight-pole circular X2 connector, with data transmission using specified pins. It operates at 24VDC with a typical power consumption of 7.5W and features isolated input and output, requiring a dedicated power source. The device is equipped with two analog outputs, does not support master communication, and provides primary encoder connectivity via HSF/RSF. Connection is made using screw terminal blocks and spring terminals, excluding solid wires for spring terminals. It supports application-specific safety I/O functions reliant on an encoder, and current control cycle times are selectable at 62.5 µs or 125 µs. Inrush current is rated at 4A. Product identification and housing information are marked on the type plate.

Technical Specifications

Data Transmission
Pins 2 and 5

Power Section
2 terminal connectors

Power Consumption
7.5W at 24VDC

Connection Points
Screw terminal blocks and spring terminals

Storage
Conductive packaging recommended

Product Designation
Indicated on type plate

Inrush Current
4A

Current Control Cycle Times
62.5μs and 125μs

Design Code
1

Control Panel Power Consumption
1W

Packaging
Customized military-grade packaging.
