R911309981 (CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth control section, MPN R911309981 (CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW), is engineered for integration in drive controllers, supporting HSF/RSF encoder connectivity via the X4 connector with a maximum output of 70 mA and a minimum load resistance of 35 Ohms. This unit features two analog differential inputs and outputs provided through an attached module on the X10 connector, with total power consumption specified at 2 W. Screw terminal blocks require the use of ferrule wire ends, and digital outputs include protection against overload and short circuits. The standard control panel permits adjustment of drive addressing, input regulation, and position data configuration.

Technical Specifications

Damage Condition
Not to be used if damaged or defective

Installation Instruction
Install as per provided documentation

Additional Devices
Might require additional sensors and actuators

X4 Connector
Fit with HSF / RSF encoder

Encoder Output Current Rating
Maximum 70mA

Encoder DC Load Resistance
Minimum 35Ohms

X8 Connector
No optional module

X10 Connector
Analog I/O extension module

Power Consumption
2W

Pulse Width
Maximum 100ms

Spring Terminal
Supports wiring with or without ferrules

Digital Outputs
Realized through high-side switches

Overload and Short Circuit Protection
Yes

Relay Contact Resistance
Maximum 1,000 milliohms

Control Panel
Helps in setting drive address and analog inputs

Delivery
Delivered through a trustworthy vendor network.

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-NN-EN1-NNN-MA1-NN-S-NN-FW.
