R911310576 (CSH01.1C-SE-EN1-EN2-EN2-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-EN2-EN2-NN-S-NN-FW Series Image

In Stock, Ships in 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911310576 (CSH01.1C-SE-EN1-EN2-EN2-NN-S-NN-FW) is a control section from the CSH series designed for integration into IndraDrive drive systems for industrial applications. Classified under IEC 61800-3 category C3 and the ADVANCED range, it features interfaces for Resolver and HSF encoder evaluation, as well as two standard 5V encoder evaluation interfaces. The module supports various encoder systems with supply voltages of DC 8V or AC 18.2V peak-peak. Communication is provided using a SERCOS interface via fiber optic cables, and configuration of transmission power and data rate is possible through the control panel or serial interface X2. It includes two analog outputs and supports master communication via the SERCOS interface. Connection terminals are implemented as screw terminal blocks and spring terminals. Supported switching frequencies are selectable between 2kHz, 4kHz, 8kHz, 12kHz, and 16kHz.

Technical Specifications

Category
IEC 61800-3 Category C3

Communication
SERCOS interface

Communication Module
Fiber optic cables

Data rate and Transmission power adjustment
Via Serial Interface X2 or Standard Control Panel

Commissioning
Via IndraWorks Software

Connection points
Spring terminals and screw terminal blocks

Switching Frequencies
2kHz, 4kHz, 8kHz, 12kHz, and 16kHz.
