R911310865 (CSH01.1C-PB-EN2-EN2-NNN-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-NNN-S1-S-NN-FW Series Image

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 44 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911310865 (CSH01.1C-PB-EN2-EN2-NNN-S1-S-NN-FW) is a Bosch Rexroth control module designed for motion control applications requiring high precision and flexibility. It supports seven to eleven digital inputs, four digital outputs, two analog outputs, and one analog input. The module provides a control current with a sampling time of 62.5 to 125 microseconds, and supports PWM frequencies up to 16 kHz while operating at 7.5 W. It integrates S1 Safety technology, a PROFIBUS communication interface, and compatibility with EnDat 2.1 encoders. Configuration and reference to technical documentation are required prior to operation.

Technical Specifications

Digital Inputs
7 to 11

Control Current
62.5 to 125 microseconds

Speed Control
125 to 250 microseconds

Position Control
250 to 500 microseconds

PWM Frequency
2 kHz to 16 kHz

Device Power Consumption
7.5 watts

Pulse Width
100 milliseconds

Inrush Current
4 amps

Analog Outputs
Two

Safety Technology
S1

Connection Module
PROFIBUS

Power Consumption of Control Panel
1 W

Digital Outputs
Four

Analog Inputs
One
