R911311179 (CSH01.1C-NN-ENS-ENS-MEM-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-ENS-ENS-MEM-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911311179 (CSH01.1C-NN-ENS-ENS-MEM-NN-S-NN-FW) is a control section intended for use with Bosch IndraDrive controllers. It features two analog outputs and has integrated support for IndraDyn, Hiperface, 1 Vpp, and TTL primary encoder options. Master communication modules are not equipped in this configuration. The unit includes a serial interface for PC connection and is compatible with a standard control panel featuring a single-line display and four-button keypad for device operation, command and error diagnostics, and monitoring of operating states. The control section supports switching frequencies from 2 kHz to 16 kHz and associated control cycle times. It comes equipped with two IndraDyn encoder modules and an encoder emulation module, with the safety module slot unpopulated.

Technical Specifications

Component
Modular control section

Part of
Bosch IndraDrive

Configuration
Standard control panel

Includes
Single line display, four button keypad

Hot plug
Not compatible

Application
Suitable for single-axis applications

Connectivity
Serial interface for PC

Switching frequencies
2 / 4 / 8 / 12 / 16 kilohertz

Current control cycle times
62.5 / 125 microseconds

Minimum SERCOS cycle time
250 microseconds

Velocity control cycle
125 / 250 microseconds
