R911311180 (CSH01.1C-PB-EN1-NNN-MEM-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-NNN-MEM-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 47 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911311180 (CSH01.1C-PB-EN1-NNN-MEM-S1-S-NN-FW) is a CSH01 series control section module utilized within the Bosch Rexroth IndraDrive system, engineered for advanced motion control tasks. This unit facilitates Resolver and HSF Encoder evaluation, supporting both absolute and incremental encoder signals through an integrated emulation system. It is equipped with two analog outputs and interfaces via PROFIBUS for communication with other automation equipment. The module includes a galvanically isolated circuit board for signal integrity and safety functionality managed through its I/O module. Drive operation parameters and diagnostics can be accessed and configured through a standard front control panel.

Technical Specifications

Product Type
Control section

Control Range
ADVANCED

Interface
Resolver and HSF Encoder Evaluation

Supply Voltage for Interface
DC 8V or AC 18.2V peak-peak

Encoder Emulation Interface
Available

Communication Option
PROFIBUS

Control Panel
Standard

Display
Single-line

Operating Keys
Four

Operation Software
IndraWorks by Rexroth
