R911311728 (CSH01.1C-SE-EN2-EN2-MEM-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-EN2-MEM-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911311728 (CSH01.1C-SE-EN2-EN2-MEM-NN-S-NN-FW) is a CSH control section utilized within Bosch Rexroth IndraDrive systems. It features dual encoder evaluation interfaces supporting various 5V encoders, and integrates a SERCOS master communication module for connection via fiber optic cable to upper-level control units. The unit includes an encoder emulation interface for replicating both absolute and incremental encoder signals, as well as two analog outputs. Configuration of SERCOS and error memory navigation is performed via the standard control panel. Supported encoder protocols include EnDat 2.1, 1 Vpp, and TTL. The device operates at switch frequencies from 2kHz to 16kHz, with a 4A inrush current, and uses spring and screw terminal blocks for connections. Maximum installation altitude is specified at 1,000 meters.

Technical Specifications

Product Type
CSH Control Section

Encoder Evaluation Interfaces
2

Communication Module
SERCOS master

Installation Type
Mountable and Dismountable (Up to 20 times)

Encoder Emulation Interface
Available

Control Panel
Standard

Switching Frequencies
2kHz, 4kHz, 8kHz, 12kHz, and 16kHz

Inrush Current
4A

Maximum Installation Height
1,000m

Firmware Support
Requires separate order

Fiber Optic Cable
Requires separate order.
